PIN-PAD TACTILION p500
- Built-in 1D/2D scanner
- Light, mobile, flexible
- Multi-connectivity: 4G/ 3G/ 2G/ WIFI/ BT (Terminal)
- Multi-connectivity: LAN/ WIFI/ USB/ RS 232 (Cradle)
CPU
Qualocomm - CORTEX - A53 (1.2 GHz, 4 cores)
Memory
RAM 1GB DDR3; Flash 8GB eMMC (Default) /RAM 2GB DDR3; Flash 16GB eMMC (Optional), support external micro TF card, 32 GB
OS
Android 9.0
Display
- 5,5" (720 x 1280) HD Colorful LCD
- Capacitive touch screen
Keypad
1 Power key, 1 physical functional keys, 3 in-screen touch keys (Menu, Back, Home)
Card readers:
- Magstripe: Support 1/2/3 Magnetic track, bi-directional swiping, support ISO7811/7812
- Smart Card: 1 IC slot, support 1.8V/3V/5V card, support ISO7816, EMV standard
- Contactless: NFC 13.56MHz, support ISO/IEC 14443, Type A/B
Communication
- 4G (FDD-LTE/TDD-LTE) + 3G (WCDMA) + 2G (GSM) (Optional)
- WLAN: 2.4G,802.11 b/g/n Inner antenna
- Bluetooth V4.2 + BLE
Security
PCI PTS 4.x, EMV L1 & L2, PayPass, PayWave, Amex, TQM, CE, ROSH
Power & Battery
- Battery: 3000 mAh lithium, 3,8V
- Input: AC100~240V, 50~60Hz, 0,3A
- Output: DC5V, 2A
Size
L x W x H = 188mm x 76mm x 18.2mm
Weight
300g including battery
Environmental parameters:
- Operating temperature: -10° to 50° C
- Storing temperature: -20° to 60° C
- Humidity: 10% to 90%, non-condensing
Multi-media
Built-in speaker, Microphone
Device Ports
1 micro-USB 2.0, 1 DC JACK, POGO PIN 5V--2A
Slots
- SAM: 2
- SIM: 1
- SD: 1
Camera
5M Pixel FF Rear Camera; flash LED, Reads 1D & 2D Codes; matrix scanner (option)
GPS Tracking
GPS, support AGPS
Multifunctional Docking Base (Optional)
Charger Cradle Base with printer and other functions
